The cabinet fits the wall. Will your trays fit through the doors?

Give every compartment a job before choosing the finish

Start with the items this cabinet will actually hold. Separate a cabinet for service supplies from one intended for cookware, ingredients or another defined use. Record the intended contents and the venue's requirements for that use; a closed door alone does not establish suitable storage conditions, segregation or a food-safety control.

Measure the complete stored item: lid, rim, handles and any proposed carrier included. A nominal container size can hide the part that catches the door. If items are to be stored together, record the complete proposed bundle envelope and quantity. Do not infer that stacking is suitable merely because a bundle has been drawn.

For each group, name the destination compartment and how often it needs to be accessed. Include the person or team using it, adjacent work and the space available in front. A cabinet beside a busy station and one used for reserve supplies can need different access arrangements even when their contents match.

Worked brief: six stored units and two offers

All contents, measurements, offers and layouts below are fictional. They illustrate a quotation screen, not a named product, tested packing method or approved installation. Dimensions are millimetres. Width means the edge presented to the cabinet front; depth runs towards the back.

Scroll the table sideways to see every column.

The buyer proposes the same row on both levels: two boxes beside one tray bundle. The required row width is 300 + 300 + 530 = 1,130. Its deepest unit is 400 and tallest is 240. These are bounding-box sums, not handling clearances or permission to store the items together. The six units are four boxes plus two bundles; a bundle is counted as one envelope, not an invented number of individual trays.

Scroll the table sideways to see every column.

Offer B wins this particular paper comparison, but it has not earned an order. Ten millimetres above a box is only 250 − 240 = 10; it is not evidence that someone can grip, lift or remove it. The 30-wide spare strip is similarly a remainder, not an approved clearance.

Offer A's width failure applies to the proposed row. It does not prove every alternative arrangement impossible. A revised layout needs its own complete allocation, with all six units still accounted for and the route to each unit shown. Do not silently remove one box to make the drawing work.

The opening can defeat a roomy interior

With overlapping sliding doors, the visible opening can be much narrower than the cabinet. Ask for the clear opening at the actual door position, including the effects of handles, tracks, stops and internal divisions. With hinged doors, show the leaf's movement and the space it occupies in the real room. A sliding arrangement and a hinged arrangement solve different access questions; neither automatically makes a cabinet accessible.

In the example, turning the tray bundle would present a 325-wide edge to Offer A's doorway. But its depth would become 530, exceeding the stated 450 depth by 80. That simple rotation therefore does not rescue the proposed storage position. A diagonal manoeuvre has not been assessed and should not become an assumed solution on the order.

Distinguish passing the opening, reaching the storage position and retrieving the intended item. A unit may pass the door but require another item to be moved before it can be removed. If that dependence matters to the service, record it. Ask for a representative demonstration or matched drawing of the complete access route rather than a photograph of an empty cabinet with its doors open.

Read the specification as a set of separate promises

A useful manufacturer example is Brayco's WALLCAB1200 specification sheet, marked October 2024 and checked on 18 October 2026. It lists an adjustable shelf and two sliding doors, gives overall dimensions and identifies installation holes with fixtures excluded. It also says dimensions are indicative and require prior approval. Those are different pieces of the buying decision, not interchangeable proof of usable storage.

Use the current matched document for the exact offered model and revision. Establish whether the mid shelf is supplied, which positions are available, what door arrangement is included and which options alter the compartments. Do not split an overall cabinet height in half to invent two clear shelf heights. Shelf thickness, tracks, frame members and adjustment positions need their own drawing or confirmation.

Have the supplier confirm permitted loading for each relevant component and arrangement, including any conditions about distribution or mounting. The example supplies no masses or ratings. Material grade, a sturdy appearance or the word “commercial” does not establish those missing ratings. Likewise, request the offered surface, joints, hardware and care requirements against the intended use rather than accepting a blanket claim that stainless steel guarantees hygiene or will tolerate every cleaning product.

Place the cabinet in the room before accepting the quote

Draw the cabinet with neighbouring appliances, benches, services and access routes. Show its overall envelope and the door-access space separately. Include handles, projections and any proposed plinth, legs or castors in the actual installed configuration. Those details can change alignment and access even when a catalogue width remains the same.

For wall-mounted storage, identify the wall construction, proposed position, contents and the responsible designer or installer. Obtain the matched fixing and loading requirements for that situation. A set of holes in a product drawing does not specify suitable anchors or prove the wall can carry the installed assembly. For base units, resolve support, levelling, bench interfaces and any required access with the relevant providers.

Keep this storage brief separate from an underbench refrigerator specification. A closed cabinet is not a refrigerated compartment. If the intended contents require controlled conditions, resolve the appropriate equipment and process independently. Similarly, a cabinet top is not automatically approved as support for a heavy or heat-producing appliance.

Make unresolved questions visible on the comparison

Scroll the table sideways to see every column.

Keep the unresolved answer beside the offer. “Supplier to confirm” is useful while comparing; it is not a confirmation. If Offer B's access demonstration fails, change the cabinet, contents or proposed layout and repeat the affected checks. Do not keep the shortlist result while discarding the assumption that produced it.

Send a compartment brief, not just a wall measurement

Your enquiry can be short if its attachments answer the right questions: contents and quantities, complete item envelopes, proposed compartment allocations, access needs, site drawing and unresolved responsibilities. Mark measured facts separately from proposed dimensions or assumptions.

Please quote enclosed storage for this contents register and layout. Confirm the exact cabinet configuration, usable compartments and door openings, demonstrate access to every proposed stored unit, identify permitted loading and intended-use conditions, and separate supplied parts from installation and site work. Flag any assumption that prevents you confirming the arrangement.
