Choose a gas oven range that can carry both sides of service

The quote says six burners and an oven. The lunch plan needs three large pans on top while two different oven jobs approach their deadlines. Counting seven places to cook hides two questions: can those pans occupy the supported positions together, and can one oven chamber satisfy both jobs?

Choose a gas oven range by proving the hob arrangement and the oven workload separately, then testing them together. One appliance can be a useful combined station, but its burner count is not a pan-placement drawing and its oven label is not a complete service plan.

The fictional comparison below exposes a paper pan-width failure and a separate shared-chamber conflict. It compares changing the range with independently specifying the hob and oven resources. For the broader choice of heat source and complete commercial proposal, use the gas and electric cooking equipment guide.

Specify the top and the oven as two linked purchases

Start with the actual pan tasks, required output and service window. Record the complete pan shape, lid, handles, loaded mass and support arrangement. Note which tasks must happen together and which can genuinely move to another part of service. A count of burners alone leaves those decisions open.

Write a separate oven brief: loaded trays, supported positions, required process or programme, loading and unloading tasks and latest acceptable handoff. A cooking top does not determine the oven beneath it. Confirm the exact offered configuration rather than assuming every range has the same chamber, controls or services.

Moffat Australia's G504D page describes a four-burner gas range with a 1/1 GN gas static oven. Its G506D page describes a six-burner range with a 2/1 GN gas static oven. These are specific configuration examples, not proof of simultaneous pan fit, usable loaded capacity or a menu result. Obtain current matched documentation for the actual model and options.

Keep the equipment family clear. A range combines a cooking top and oven in one appliance; a stand-mounted hob and separately located oven form a different proposal. Deck, combi and convection ovens need their own task evidence. Do not treat all gas-heated chambers as interchangeable because they use the same fuel.

Worked hob screen: three pans do not equal three usable positions

All dimensions and arrangements here are invented. Assume the proposed menu needs pans P1, P2 and P3 together during the 11:20–11:35 planning window. Their nominated body diameters are 320, 280 and 240 mm. This is a preliminary drawing exercise, not a permitted cookware arrangement or a heating demonstration.

The fictional proposal allocates an 800 mm-wide strip for a single row. Assume the brief requires all three circular bodies fully inside it without overlap. The body widths alone add to 320 + 280 + 240 = 840 mm, exceeding the strip by 40 mm. Handles, support, burner alignment and operating access have not even entered the calculation.

Scroll the table sideways to see every column.

A second row is another arrangement to draw, not permission to move a pan to an unsupported position. Show the actual front-to-back dimensions and centre locations, plus neighbouring pans and handles. The width failure proves only that the stated single-row arrangement fails. It does not prove that no arrangement can ever work on the offered appliance.

Likewise, 160 mm or 20 mm left over is arithmetic space, not an acceptable gap or operating allowance. A larger body can overhang a nominated support or miss the intended position even when the overall rectangle looks generous. Have the provider assess the exact loaded combination under the manufacturer's instructions.

Worked oven plan: the larger top does not add another chamber

The same fictional service has two oven jobs. Job O1 is assigned 11:10–11:35 under programme A. Job O2 is assigned 11:20–11:40 under programme B, with a latest handoff of 11:45. For this exercise, assume the responsible task brief says A and B cannot share one chamber at the same time.

These are invented resource reservations, not recipes, cooking times, settings or evidence that any product is ready. They represent complete reserved blocks for the arithmetic; actual load, transition and handoff requirements must be established. No extra unrecorded changeover is assumed to be zero in a real purchase.

Scroll the table sideways to see every column.

The initial reservations occupy 25 and 20 minutes respectively. They overlap for fifteen minutes. Serial allocation takes 45 minutes from 11:10 to 11:55; it does not fit the O2 deadline. Increasing the hob's paper width changes none of that oven arithmetic.

A second chamber removes this particular shared-resource conflict only if each proposed oven supports its assigned load and process, and the team can manage the simultaneous work. The five-minute remainder is not a guaranteed operational buffer. Loading, access, programme readiness and handoff evidence still decide whether the actual proposal meets the brief.

If the real food processes can share a programme or run in a different sequence, retain the evidence and revise the model. Do not invent compatibility, earlier production or a holding method merely to rescue the single-chamber option. The oven batch-map guide develops that separate programme and finish-time investigation.

Compare the combined range with a complete separate arrangement

Retain a combined range on the shortlist when its actual top supports the required simultaneous pans and its oven satisfies the independent load and deadline brief. Demonstrate the combined task too: an oven unload beneath active hob work can introduce an access or staffing question missing from two separate demonstrations.

A wider combined range may resolve the top arrangement while leaving the oven conflict unchanged. A separate hob and oven proposal lets their requirements be selected independently, but adds its own footprint, services, landing and handoff decisions. Two ovens are not automatically better than one; they are a proposal to test against the recorded constraint.

Make each quote describe the whole arrangement. Identify the exact top, oven or ovens, pans, trays, supports and included options. Ask whether the nominated configurations support the simultaneous workload rather than treating separate maximum ratings as evidence for combined use.

Compare access for cleaning, instructed care and service, and establish what happens if one part becomes unavailable. Do not assume an oven fault necessarily stops the hob, or that separate appliances guarantee uninterrupted service. Obtain the actual operating and service implications from the provider.

Resolve the site and gas configuration from the exact offer

Record the proposed gas configuration and existing site information, then have the appropriate appointed providers establish suitability, connection and commissioning requirements. Do not infer interchangeability from a model family name or attempt to plan a conversion from this article.

Obtain matched installation documents for the complete appliance and neighbouring equipment. Ventilation, services, operating access and required approvals belong to a site-specific assessment. This guide supplies no gas fitting, pressure, clearance, exhaust quantity or installation procedure.

When a proposed layout or model changes, use the fitout services coordination guide to retain current drawings and affected responsibilities. That is a separate question from proving the pan and chamber plan.

Keep running costs outside this paper capacity screen. Input ratings, fuel labels and the fictional reservation times do not establish measured consumption or a cheaper option. Any financial comparison needs comparable work, actual consumption boundaries, tariffs and complete installation scope.

Prepare the shared-workload brief

For your own supplier brief, record simultaneous pans, actual envelopes, oven and hob dependencies, landing needs and demonstrated task results. Replace the fictional inputs with actual evidence and leave unresolved decisions visible.

Please assess these exact simultaneous pan tasks and oven reservations against your complete offer. Show the supported loaded top arrangement and chamber allocation, demonstrate the combined handoff, and identify unresolved model, services, access and process requirements. Price alternatives as complete configurations.

Use the brief with Atlantic's gas ovens and ranges, or send the full workload requirement. The useful answer is an arrangement that can substantiate both sides of the purchase, with open decisions kept visible.

Sources and example boundaries

Manufacturer sources checked 18 October 2026: Moffat Australia's G504D and G506D product pages, for their named top and oven configurations only. No manufacturer dimensions, burner ratings, oven programme or operating instruction is assigned to the fictional proposals.

All pan dimensions, strip widths, reservation times, programme labels and deadlines are invented. No actual cookware approval, product result, gas installation suitability, staffing level, operating saving or Atlantic stock availability is claimed.
